Technical Specifications
| Code |
D |
L |
|
Code |
D |
L |
| PVFRC050x10 |
50 |
90 |
PVFRC250x10 |
250 |
320 |
| PVFRC063x10 |
63 |
100 |
PVFRC280x10 |
280 |
350 |
| PVFRC075x10 |
75 |
110 |
PVFRC315x10 |
315 |
285 |
| PVFRC090x10 |
90 |
140 |
PVFRC355x10 |
355 |
435 |
| PVFRC110x10 |
110 |
160 |
PVFRC400x10 |
400 |
480 |
| PVFRC140x10 |
140 |
200 |
PVFRC450x10 |
450 |
530 |
| PVFRC160x10 |
160 |
220 |
PVFRC500x10 |
500 |
590 |
| PVFRC180x10 |
180 |
240 |
PVFRC540x10 |
540 |
600 |
| PVFRC200x10 |
200 |
260 |
PVFRC560x10 |
560 |
635 |
| PVFRC225x10 |
225 |
300 |
|
|
|
Note : • All dimensions are in mm.
• All fabricated fittings are available in 10 kg/cm² pressure rating. Please specify other pressure ratings as per the requirement viz. 04, 06, 08, 12.5 kg/cm². eg. for PVC Quick Fix Bend 45°, 20mm size and 6 kg/cm² pressure rating, specify code as PVFBQ45063X06.
